Welcome to Sun Avionics

Manufacturer of the lightweight and affordable model AV-10, AV-15 and AV-17 personal and professional ramp testers for performing accurate functional checks of your avionics equipment.
An invaluable tool for pilots, flight schools, FBO's and aircraft repair facilities.

AV-10 AVIONICS RAMP TESTER

The AV-10 is a small, battery operated, light-weight, yet powerful tool that tests the following aircraft electronic systems:

VOR

ILS (localizer, glideslope, markers)

DME

ADF-NDB

MODE A/C/S 1090ES ADS-B TRANSPONDER

Price: $1,315.00 each + shipping
Recalibration Fee: $100.00 + shipping
30 day return and 1 Year parts and labor warranty SPECS

AV-15 AVIONICS RAMP TESTER

The AV-15 has a scope trigger output for bench use and can be powered via it's micro USB port. It includes all the functionality of the AV-10 and adds the following enhanced measurement capabilities:

Transponder output power measurement for mode A, mode C, and mode S

Detect power droop as required in Australia

Minimum Trigger Level MTL measurement for all three modes

-9dbm sidelobe suppression

Transponder receive frequency

COMM radio test functions

1090 Traffic Sim

Price: $1,865.00 each + shipping
Recalibration Fee: $150.00 + shipping
30 day return and 1 Year parts and labor warranty SPECS

AV-17 AVIONICS RAMP TESTER

The AV-17 has a scope trigger output for bench use and can be powered via it's micro USB port. It includes all the functionality of the AV-15 and adds the following enhanced measurement capabilities:

UAT ADS-B READ

UAT 978 TRAFFIC SIM

Price: $2,145.00 each + shipping
Recalibration Fee: $175.00 + shipping
30 day return and 1 Year parts and labor warranty SPECS

AV Comparison Chart
FUNCTIONS	AV-10	AV-15	AV-17
VOR
VOR SIGNAL AT EVERY 45° STEP, ID TONE	✓	✓	✓
ILS
LOCALIZER CENTER; 1/2 L&R, FULL L&R, 90Hz & 150Hz OFF	✓	✓	✓
GLIDE SLOPE CENTER; 1/2 U&D, FULL U&D, 90Hz & 150Hz OFF	✓	✓	✓
MARKER BEACONS; OUTER, MIDDLE, INNER	✓	✓	✓
DME
X & Y 20 MILE FIXED RANGE SIMULATION	✓	✓	✓
ADF-NDB
400KHZ, 450KHZ, 650KHZ, 1.2MHZ RECEIVE TEST	✓	✓	✓
COMM RADIO TEST
RECEIVER TEST		✓	✓
TRANSMIT FREQUENCY CHECK		✓	✓
1090 MHZ TRANSPONDER A/C/S/ADS-B
MODE-A	✓	✓	✓
MODE-C	✓	✓	✓
Tx FREQUENCY CHECK	✓	✓	✓
Rx FREQUENCY CHECK		✓	✓
POWER AND MTL CHECK		✓	✓
SLS TIME CHECK	✓	✓	✓
A/C/S ALL CALL	✓	✓	✓
ATCRBS ALL-CALL	✓	✓	✓
S ONLY ALL-CALL	✓	✓	✓
S MODE DF-4 ALTITUDE READ	✓	✓	✓
S MODE DF-5 SQUAWK READ	✓	✓	✓
S MODE DF-20 READ	✓	✓	✓
S MODE DF-21 READ	✓	✓	✓
ID SQUITTER ADS-B	✓	✓	✓
TAIL NUMBER SQUITTER ADS-B	✓	✓	✓
STATUS SQUITTER ADS-B		✓	✓
AIR VELOCITY SQUITTER ADS-B		✓	✓
AIR LOCATION SQUITTER ADS-B	✓	✓	✓
GROUND LOCATION SQUITTER ADS-B		✓	✓
TEST SQUITTER	✓	✓	✓
1090 TRAFFIC SIMULATION
STEP SIMULATED AIRCRAFT LEFT/RIGHT		✓	✓
978 MHZ UAT
UAT ADS-B READ			✓
STEP SIMULATED AIRCRAFT UP/DOWN			✓
µAVIONIX SYNC ver 3.04 up			✓
